Copper Dual-Rated Lay-In Ground Lug 14-4-AWG Tin Plated Solar

Copper Lay IN Lugs Copper ground Lugs Specifications

Description

Grounding-Bonding Cable Terminal Lugs: Type – Lay-In Ground Lug; Material – Copper, Tin Plated; Lug L x Tongue W – 1.070 x 0.380 in; Stud Holes – 1; Conductor Type – CU Cable; Conductor Size – AWG MCM – 10 – 4 str; Screw/Stud Size – #10; Additional Information – Approved for Direct Burial. Slot Head Screw; Manufacturer Series – CULL

Additional Info: Approved for Direct Burial. Slot Head Screw

We are one of the largest manufacturers exporters and suppliers from India of copper lay in lugs Copper ground lugs Copper Solar Lugs. The Lugs are made from high conductivity extruded Copper and supplied with Stainless Steel slotted screws,



Copper Lay in Lugs-Copper Ground lugs: Typical Questions.



Understanding Copper Lay in Lugs and and Copper Ground Lugs – Technical Questionnaire

What are Copper Lay in Lugs and their primary function? Copper Lay in Lugs are specialized electrical connectors designed for quick and efficient conductor termination. These Copper Lay in Lugs feature an open-sided design allowing conductors to be laid in rather than inserted through the barrel. Copper Lay in Lugs are particularly valuable in retrofit and maintenance applications where wire access is limited.

What materials are used in Copper Lay in Lugs? Copper Lay in Lugs are manufactured using:

• Electrolytic copper: 99.9% pure
• Tin plating options available
• Lead-free construction These materials ensure Copper Lay in Lugs maintain optimal conductivity and corrosion resistance.

What size ranges are available for Copper Lay in Lugs and Copper Ground Lugs? Copper Lay in Lugs accommodate various conductor sizes:

• Wire Range: #14 AWG to 1000 MCM
• Stud Sizes: #6-32 to 1/2″ bolt diameter
• Barrel Length: According to UL standards Copper Lay in Lugs are available in both standard and long barrel versions.

What certifications apply to Copper Lay in Lugs? Copper Lay in Lugs meet multiple standards:

• UL Listed to 486A-486B
• CSA Certified to C22.2
• RoHS Compliant
• ISO 9001 Manufacturing Each Copper Lay in Lug carries appropriate certification markings.

What installation methods are used for Copper Lay in Lugs? Copper Lay in Lugs installation requires:

• Conductor Preparation:
  • Clean conductor surface
  • Proper strip length
  • Optional wire brushing
• Compression Tools:
  • Matching die sets
  • Calibrated compression tools
  • Proper compression sequence

What are the torque specifications for Copper Lay in Lugs? Copper Lay in Lugs require specific torque values:

• #6-32: 20-25 in-lbs
• #8-32: 25-30 in-lbs
• #10-32: 30-35 in-lbs
• 1/4-20: 65-75 in-lbs
• 3/8-16: 200-250 in-lbs
• 1/2-13: 400-450 in-lbs

What temperature ratings apply to Copper Lay in Lugs? Copper Lay in Lugs are rated for:

• Operating Temperature: 90°C
• Maximum Short-term: 150°C
• Current Rating: Based on wire size
• Temperature Rise: <30°C above ambient

What are the mounting options for Copper Lay in Lugs and Copper Ground Lugs? Copper Lay in Lugs offer various mounting configurations:

• Single Hole Mounting
• Two Hole NEMA Spacing
• Custom Hole Patterns
• Stacking Capabilities Each Copper Lay in Lug design meets specific application requirements.

How should Copper Lay in Lugs be maintained? Maintenance for Copper Lay in Lugs includes:

• Regular Inspection:
  • Check for oxidation
  • Verify torque settings
  • Examine for damage
• Cleaning Requirements:
  • Remove oxidation
  • Clean contact surfaces
  • Apply joint compound if needed

What environmental factors affect Copper Lay in Lugs? Copper Lay in Lugs performance is influenced by:

• Indoor/Outdoor Rating
• Moisture Exposure
• Chemical Environment
• Temperature Cycling
• UV Exposure Proper selection of Copper Lay in Lugs ensures optimal performance in specific environments.

What are common applications for Copper Lay in Lugs and Copper Ground Lugs? Copper Lay in Lugs are commonly used in:

• Power Distribution Panels
• Motor Connections
• Transformer Terminations
• Service Entrance Equipment
• Industrial Control Panels Each application requires specific Copper Lay in Lug configurations.
